3. PaX-i Imaging System Overview
Item Details
NASAL POSITIONER
-
Positions the patient during CEPH
imaging.
-
The ruler for use to compensate the
acquired image that is different from
actual size.
SECONDARY COLLIMATOR
Limits the X-Ray irradiation eld for CEPH
scanning.
BASE
Used to balance and stabilize the
equipment.
LED LAMP
Indicates current exposure activity.
-
Green: Ready
-
Orange: X-Ray On
ROTATING UNIT
Rotates around the patient’s head during
exposure (depending on the imaging
mode).
X-RAY SENSOR (PANO)
Sensor: used for PANO imaging.
X-RAY TUBE
The source of X-Ray emission.
TEMPLE SUPPORT
Supports the patient’s temples during
PANO scan.
CHIN SUPPORT
Supports the patient’s chin during imaging.
COLUMN Up/down
BUTTON
Moves the Column up/down
LASER BEAM ON / OFF
BUTTON
Turn the laser beam on / off
EMERGENCY SWITCH
Cuts off all power to the equipment in case
of emergency. Its primary function is to
protect the patient from a severe injury and
the equipment from damage.
HANDLE FRAME
Held firmly by the patient during imaging to
stabilize his / her position.
ON / OFF SWITCH
Turns the equipment on or off.
TELESCOPIC COLUMN
Moves the column up or down for patient
positioning.
COLUMN Up/down
SWITCH
Moves the Column up/down (optional)
STATIONARY COLUMN
The portion of the column fixed to the
base.
