PaX-i (PCH-2500) User Manual

4. Software Overview

C. Arch Selection

Select the patient’s arch type: Narrow, Normal, Wide, Child, and Orthogonal.

Orthogonal: Enables the image to be acquired with overlapping regions of the

teeth minimized.

D. PANO Examination

Acquire the image for a specic ROI in panoramic mode.

Mode

Region of Interest:

PANO Image

Remark

Standard

Imaging standard

images

Supported by

any arch type

selection

Right Imaging lateral right

Front Imaging frontal area

Left Imaging lateral left

The following table summarizes the sub-modes for orthogonal imaging.

Orthogonal mode:

Acquires an image that minimizes overlapping regions of

teeth.

Pi_u272_en_20180514.indd 48 2018-05-14 오전 11:03:17
