VEMAG ROBOT HP7E - Six-monthly Maintenance: Feed Unit Seals and Hydraulic Unit Oil Level

ROBOT HP7E / HP10E / HP12E / HP15E / HP20E8. Maintenance
8-14 © VEMAG 2010
8.8 Six-monthly maintenance
8.8.1 Feed unit seals
• Have the feed unit seals checked by VEMAG Customer Service.
8.8.2 Hydraulic unit (oil level)
The hydraulic unit for the lifting and tipping device (optional) is located
behind the service hatch on the rear of the machine. There is a sight
glass for checking oil level on the front of the hydraulic unit. The oil
should come at least to the centre of the sight glass.
• Open the service hatch on the right-hand side.
• Check the oil level of the hydraulic unit through sight glass (1) provi-
ded and top up oil through ller neck if necessary.
1 Sight glass
Fig. 8-14
Oil level of the hydraulic
unit
1
• Close the service hatch again.
Considerable or continuous lack of oil indicates a leak which must be
eliminated.
8.8.3 Vacuum pump 16 m³ and 40 m³ (optional)
Operating instructions for vacuum pump
