VEMAG ROBOT HP7E - Double Screw Selection Guide; Filling Horn Selection Guide

ROBOT HP7E / HP10E / HP12E / HP15E / HP20E10. Appendix
10-14 © VEMAG 2010
10.10 Accessories
10.10.1 Double screw selection
The following double screws are recommended for setting up the lling
machine as a function of the product to be processed.
Type of double screw Application Order no.
72-367HZ for boiled sausage, salami (without
grinder)
912310048
72-367HPZ for boiled sausage, salami (without
grinder)
912310098
72C/72SC/36N-367HPZ for boiled ham, ground beef 945348720
112C/112SC/48N-452HPZ for boiled ham, ground beef 947448930
48C/72SC/48N-367HPZ for grinder applications 942378639
66C/66SC/48N-367HPZ for grinder applications 944378639
Warning!
For grinder applications, use only the double screws in the list above.
10.10.2 Filling horn selection
The following lling horns are available for straight lling.
Horn dia. Filling horns to DIN 9798 Filling horns with crowned outlet
8 901100080 -
9 901100090 -
10 901100100 -
12 901100120 -
13 901100130 -
14 901100140 -
15 901100150 -
16 901100160 901500160
18 901100180 901500180
20 901100200 901500200
22 901100220 901500220
24 901100240 901500240
28 901100280 901500280
30 901100300 901500300
35 901100350 901500350
40 901100400 901500400
45 901100450 -
50 901100500 -
55 901100550 -
60 901100600 -
