ROBOT HP7E / HP10E / HP12E / HP15E / HP20E 6. Graphical control
6-3© VEMAG 2010
6.1 Control panel
The colour screen and the keys are integrated in the green control panel.
The screen is divided into various elds.
Section 6.2
There are seven function keys to both the left and the right of the screen
which you use to activate the associated area of the screen.
Use the keypad on the right-hand side of the screen to make entries.
Section 6.3
