ROBOT HP7E / HP10E / HP12E / HP15E / HP20E6. Graphical control
6-40 © VEMAG 2010
6.6.4.23 End of stick
Display: End of stick
Selection: Stop / lled portions
Unit: Number
Resolution: 1
Setting range: 0 – 10 (default = 0)
Application: Hanging
• Enter the number of sausages inserted to generate a gap between
two sections (smoke sticks).
• Press Enter.
Selecting "Stop" makes this parameter into the stop counter.
6.6.4.24 End of portioning (LPV 802 and DHV 841 only)
Display: End of portioning
Selection: Immediate / Even number
Application: Hanging (LPV 802 and DHV 841 only)
• Enter criterion for stopping the machine.
• Press Enter.
Select "Immediate" if you intend stopping portioning by actuating the
knee lever. Select "Even number" if the machine is to stop at an even
number of portions after the knee lever has been actuated. For example,
if you have produced seven portions when the knee lever is actuated,
the machine pumps the eighth portion before stopping.
6.6.4.25 Extra hook
Display: Extra hook
Unit: Number
Resolution: 1
Setting range: 0 – 10
Application: Hanging
• Enter the number of extra hooks still to be cycled after actuation of the
knee lever.
• Press Enter.
Extra hooks are inserted before the line on the LPV 802 and DHV 841
and after the line on the LPG.
