ROBOT HP7E / HP10E / HP12E / HP15E / HP20E 10. Appendix
10-15© VEMAG 2010
10.10.3 Linking horns
The linking horn should be selected as a function of the casing holding
device used. To select a suitable linking horn
Casing holding device operating instructions
10.10.4 Miscellaneous accessories
Component Use Order no.
Filling horn holder for 367 mm double screws 936315000
Filling horn holder for 454 mm double screws 936316002
Filling horn nut for attaching lling horn 930100017
Blind plug double screw housing 920001010
Cleaning plug vacuum line intake pipe 142300600
10.10.5 Tools
The following tools are required for daily cleaning and for maintaining the
machine.
Tool Use Order no. Scope of supply
Atomizer canister lubrication 067287501 yes
Grease gun lubricating feed system 067064001 yes
Grease gun hose lubricating feed system 067064002 yes
WAF 80/30/50 universal
spanner
lling horn nut,
adjustable feet,
knee lever,
linking head,
trolley hoist
126030041 yes
WAF 13/17 double span-
ner
trolley hoist, mirror 069120131 yes
Face spanner guard ring and setting ring
on drive of lifting/tipping
device (optional)
069171251 yes
Threaded screw extractor double screws held at rear 110930010 yes
Hooked screw extractor double screws held at front 110930111 -
Threaded screw extractor double screws with tape-
ring front
118031000 -
Extraction device double screw housing 114038000 yes
