ROBOT HP7E / HP10E / HP12E / HP15E / HP20E 6. Graphical control
6-39© VEMAG 2010
6.6.4.20 Sausages per hook
Display: Sausages per hook
Unit: Number
Resolution: 1
Setting range: 1 – 99
Application: Hanging
• Enter the number of sausages to hang between the hooks.
• Press Enter.
The number should be divisible by 2. If you would like to hang rings, enter "1".
6.6.4.21 Catch position
Display: Catch position
Unit: Millimetre [mm]
Resolution: 1 mm
Setting range: -999 – +999 mm (default = 0 mm)
Application: Hanging
• Enter the position in which the hook catches the link.
• Press Enter.
If the hook is reaching into the link too early, the value needs to be increased;
if the hook is reaching into it too late, the value needs to be reduced.
6.6.4.22 Sausages per stick
Display: Sausages per stick
Unit: Number
Resolution: 1
Setting range: 1 – 999
Application: Hanging
• Enter the number of sausages to be taken up by one smoke stick.
• Press Enter.
