6.6.4 Supplementary parameters
The supplementary parameters are displayed on the right-hand side of
the screen. These parameters can be summarized in parameter sets for
your applications. It is possible to scroll through the parameters.
The basic parameters (e.g. weight) are explained in a previous section.
Section 6.6.2
General applications
6.6.4.1 Speed of feed unit screw
Display: Infeed
Setting range: Dynamic (default = 1.00)
Application: Setting the speed of the feed unit screw
• Enter speed of feed unit screw.
• Press Enter.
The speed of the feed unit screw is adjusted automatically as a function
of the feed element. If required, you can adapt speed innitely using this
parameter.
If the feed unit screw is also to rotate during the pause, place a tick in the
"continuous" eld by pressing the Enter key.
6.6.4.2 Feed unit run-on
Anzeige: Feed unit run-on
Einheit: Seconds [sec]
Auösung: 1 sec
Einstellbereich: 0 - 999 sec
Anwendung: Feed screw run-on
• Enter the feed screw run-on.
• Press Enter.
Enter an amount of time here for how long the feed unit drive should
screw beyond the portion end.
6.6.4.3 First link
Display: First twist
Unit: Number
Resolution: 0.1
Setting range: 0 – 6.3
Application: Linking
• Enter addition for the rst link.
• Press Enter.
