VEMAG ROBOT HP7E - Technical Data for ROBOT HP Models

ROBOT HP7E / HP10E / HP12E / HP15E / HP20E10. Appendix
10-2 © VEMAG 2010
10.2 Technical data ROBOT HP7E / HP10E / HP12E / HP15E / HP20E
ROBOT HP7E ROBOT HP10E ROBOT HP12E ROBOT HP15E ROBOT HP20E
Filling rate with
double screw
48/80 up to 3,600 kg/h up to 5,600 kg/h up to 3,600 kg/h up to 6,500 kg/h up to 4,600 kg/h
66/80 up to 5,100 kg/h up to 8,000 kg/h up to 5,200 kg/h up to 9,300 kg/h up to 6,600 kg/h
72/80 up to 5,500 kg/h up to 8,600 kg/h up to 5,600 kg/h up to 10,000 kg/h up to 7,000 kg/h
112/80 - up to 14,000 kg/h up to 9,100 kg/h up to 16,200 kg/h up to 11,400 kg/h
72/90 - - up to 8,000 kg/h up to 14,200 kg/h up to 10,000 kg/h
112/90 - - up to 13,700 kg/h up to 24,300 kg/h up to 17,000 kg/h
Portion size: 5 - 99,999 g,
adjustable in
increments of 0.1 g
or 1 g
5 - 99,999 g,
adjustable in
increments of 0.1 g
or 1 g
5 - 99,999 g,
adjustable in
increments of 0.1 g
or 1 g
5 - 99,999 g,
adjustable in
increments of 0.1 g
or 1 g
5 - 99,999 g,
adjustable in
increments of 0.1 g
or 1 g
Portion speed: > 650 portions/
min. (depends on
product, casing and
portion size)
> 750 portions/
min. (depends on
product, casing and
portion size)
> 700 portions/
min. (depends on
product, casing and
portion size)
> 650 portions/
min. (depends on
product, casing and
portion size)
> 600 portions/
min. (depends on
product, casing and
portion size)
Number of links: 0 - 10, innitely
adjustable
0 - 10, innitely
adjustable
0 - 10, innitely
adjustable
0 - 10, innitely
adjustable
0 - 10, innitely
adjustable
Vacuum system: 16 m
3
/h 16 m
3
/h / 40 m
3
/h
(optional)
16 m
3
/h / 40 m
3
/h
(optional)
16 m
3
/h / 40 m
3
/h
(optional)
16 m
3
/h / 40 m
3
/h
(optional)
Hopper capacity: 250 l / 350 l
(optional)
250 l / 350 l
(optional)
250 l / 350 l
(optional)
350 l 350 l
Height adjustable
by:
80 mm (1,000 -
1,080 mm)
80 mm (1,000 -
1,080 mm)
80 mm (1,000 -
1,080 mm)
80 mm (1,000 -
1,080 mm)
80 mm (1,000 -
1,080 mm)
Total weight inclu-
ding lifting/
tipping device
(optional):
approx. 1,220 kg approx. 1,240 kg approx. 1,240 kg approx. 1,250 kg approx. 1,250 kg
Noise emission: < 75 db(A) < 75 db(A) < 75 db(A) < 75 db(A) < 75 db(A)
Power input: 10 kW at 50/60 Hz 14 kW at 50/60 Hz 14 kW at 50/60 Hz 20 kW at 50/60 Hz 20 kW at 50/60 Hz
Main motor: 3.8 kW at 50/60 Hz 7.3 kW at 50/60 Hz 7.3 kW at 50/60 Hz
13.1 kW at 50/60 Hz 13.1 kW at 50/60 Hz
Current consump-
tion at
220 - 240V, 50/60 Hz 26 A 36 A 36 A 64 A 64 A
400 - 480V, 50/60 Hz 15 A 21 A 21 A 37 A 37 A
Electrical ttings: to DIN EN 60204-1
Protection (exterior): IP 65
Protection (interior): IP X3
Type of mains connection for TNS mains equipment protection class I
(earth wire)
