ROBOT HP7E / HP10E / HP12E / HP15E / HP20E 9. Troubleshooting
9-1© VEMAG 2010
9. Troubleshooting
9.1 General information
Any attachments or additional devices (optional) which may be present
should be disconnected from the lling machine for troubleshooting pur-
poses. The relevant safety instructions must be followed. Possible faults,
causes and the measures you need to take to remedy them are listed
below.
9.2 Troubleshooting table
Fault Cause Remedy
Machine does not start. Hopper open.
No lling horn holder.
Source of fault shown in display.
Check part displayed.
Vacuum pump not running. Power switch QM4 triggered.
Vacuum pump overloaded.
Switch on power switch.
Check vacuum pump.
Display does not light up. No mains voltage.
Main switch not on.
Fuse F1, F2, F3 defective.
Power supply or graphic control
defective.
Have machine back-up fuse re-
placed by electrician.
Switch on main switch.
Have fuse replaced by electrician.
Have defective part replaced by
electrician.
Vacuum level not reached, vacuum
unstable.
Leak in vacuum system.
Water or product residues in line to
display.
Air de-oiling element contaminated.
Check vacuum system.
Clean or replace line.
Replace air de-oiling element.
Machine temperature too high. Air lter contaminated. Clean air lter.
Lifting/tipping device (optional) not
functioning.
Buttons not reacting.
Valve Y1, Y2 is not actuated or is
defective.
Hoist motor not running.
Power switch QM5 triggered.
Inform VEMAG Customer Service.
Check valve, voltage is shown by
LED below the valve plug.
Check hoist motor.
Switch on power switch.
