ROBOT HP7E / HP10E / HP12E / HP15E / HP20E3. Installation and commissioning
3-4 © VEMAG 2010
3.3 Electrical connection
Danger!
To prevent injury (electric shock), the electrical connection may be made
only by authorised specialist staff or specialist companies.
• Inside the machine housing, connect the machine to the main switch
(1) of the machine using four-core cable with 3 x phase and 1 x earth
wire. There is a cable conduit in the base-plate. For correct connection
values
Section 10
1 Main switch
Fig. 3-5
Electrical connection
1
