ROBOT HP7E / HP10E / HP12E / HP15E / HP20E 8. Maintenance
8-21© VEMAG 2010
8.11 Three-yearly maintenance
8.11.1 Feed drive (oil change)
The oil in the transmission of the feed drive needs to be changed every
three years.
• Unlatch the toggle on the rear of the machine and open the cover
completely.
• Remove the service hatch on the rear of the machine.
• Undo oil drain screw (1) and drain the oil into a suitable container.
• Drain off the used oil and screw the oil drain screw back up.
1 Oil drain screw
Fig. 8-22
Changing the oil in the
feed drive
1
