VEMAG ROBOT HP7E - Fitting the Scraper

ROBOT HP7E / HP10E / HP12E / HP15E / HP20E 4. Setting up
4-9© VEMAG 2010
4.8 Fitting the scraper
A scraper can be tted to the hopper for product which sticks to the wall
of the hopper. The scraper must be used when processing raw sausage.
Danger!
There is a risk of crushing when tting and removing the scraper. To
prevent injury, proceed extremely carefully when tting and dismantling
the part.
• Put the scraper (1) on the locking pin (2) of the feed screw and make
sure it engages.
1 Scraper
2 Locking pin
Fig. 4-14
Fitting the scraper
1
2
