ROBOT HP7E / HP10E / HP12E / HP15E / HP20E3. Installation and commissioning
3-2 © VEMAG 2010
• Drive the lifting truck / fork-lift truck in under the machine so that fork
(1) is located precisely centrally between the feet.
Warning!
Place planks (2) between the fork and the machine to prevent the machi-
ne slipping during transportation. You must ensure that the fork and the
planks are pushed right under the machine so that the connection cable
is not damaged by the fork.
1 Fork
2 Plank
Fig. 3-3
Transporting the machine
1
2
