7.13 BCB Reference Current and Connection
Table 7.4 below provides recommended BCB rated current and battery maximum discharge current at full load. Refer to Table
3B in IEC60950-1, and select appropriate cable CSA according to local electrical codes and standards..
Item s Unit
UPS ra ted p ower (k V A )
25 0
28-block battery
Rated battery discharge current at full load A 897
Reference rated current of BCB A -
CSA of connection cable mm
2
2 × 240
30-block battery
Rated battery discharge current at full load A 897
Reference rated current of BCB A -
CSA of connection cable mm
2
2 × 240
32-block battery
Rated battery discharge current at full load A 857
Reference rated current of BCB A -
CSA of connection cable mm
2
2 × 240
34-block battery
Rated battery discharge current at full load A 806
Reference rated current of BCB A -
CSA of connection cable mm
2
2 × 240
36-block battery
Rated battery discharge current at full load A 761
Reference rated current of BCB A 800
CSA of connection cable mm
2
2 × 240
38-block battery
Rated battery discharge current at full load A 720
Reference rated current of BCB A 800
CSA of connection cable mm
2
2 × 185
40-block battery
Rated battery discharge current at full load A 683
Reference rated current of BCB A 800
CSA of connection cable mm
2
2 × 185
42-block battery
Rated battery discharge current at full load A 650
Reference rated current of BCB A 800
CSA of connection cable mm
2
2 × 185
44-block battery
Rated battery discharge current at full load A 620
Reference rated current of BCB A 800
CSA of connection cable mm
2
2 × 185
Table 7.4 BC B rated current and battery m ax. discharge current at full load (recom m ended)
N O T E: W hen the battery is under 34 -block, the BCB sh ould be cu stom ized.
