3.4 Unpacking
Unpack the UPS and battery packages under the guidance of authorized service engineer. Follow the steps given below:
Figure 3.2 Rem oving th e p acking belts and honeycom b board s
N o. Descriptio n
1 Packing belt
2 Carton box
3 Top cover
4 Honeycomb board
1. As shown in Figure 3.3 below, remove the packing belts and honeycomb boards.
Figure 3.3 Rem oving th e p acking belt, honeycom b board s and carton box
2. As shown in Figure 3.4 on the facing page, remove the honeycomb board.
3 Mechanical Installation
21
Vertiv™ Liebert® APM Plus User Manual
