3.2 Transportation
Railroad transportation and shipping are the recommended means of transportation. If truck transportation is unavoidable,
choose roads that are less bumpy in order to protect the equipment.
The UPS cabinet is heavy (see Table 12.3 on page173 for the weight). We recommend using mechanical equipment such as
an electric forklift to unload and move the equipment to the place closest to the installation site. If an electric forklift is used,
insert the tines of the forklift below the bottom pallet (as shown in Figure 3.1 below) to prevent the equipment from falling
over. During transportation, the tipping angle of the cabinet cannot exceed 15 degrees.
Figure 3.1 Insertin g and movem ent (C abinet front)
N o. Descriptio n
1 Forklift insertion direction
3.3 Tools
W ARN ING ! F or the sake of safety, the installation tools under live operation must be
insulated .
W ARN ING ! T ools in Table 3.1 on the facing page are for reference only; please follow the
actual requirem ent for on-site installatio n an d connectio n.
3 Mechanical Installation
19
