9.2.5 Seismic Anchor Kit
The UPS provides seismic anchor kits to avoid and reduce the damage to UPS caused by earthquake or vibration.
See Table 9.2 below for dimensions of the seismic anchor kit.
Se ism ic an ch or W idth (m m ) L eng th (m m ) Torq ue value (N .m )
Seismic anchor 60 585 13
Table 9.2 D im ensions of the seism ic anchor kits
Fix the UPS onto the concrete floor.
W ARN ING ! O nly Vertiv authorized engineers shall carry ou t th e in stallation.
W ARN ING ! C arry out the in stallation strictly follow ing the instructions. Failure to ob serve this
could cause personnel in jury or dam age to the UP S and seism ic anchor kits.
Preparation
1. Prepare the installation tools, including a cross head screwdriver, a torque spanner and an adjustable spanner.
2. Check that all installation materials are present and complete, including two seismic anchors, eight M8 × 25
tapping screws, six M12 expansion bolts.
Procedures
The installation procedures are as follows:
1. Use M8 × 25 tapping screws (4 pcs) to install seismic anchor on the rear bottom of the UPS cabinet, and use M12
expansion bolts (3 pcs) to fix seismic anchor on the ground, as shown in Figure 9.5 on the next page.
