9.2.16 I/O Switch Assembly
As shown in Figure 9.14 below, the I/O switch kit includes input switch, output switch and bypass switch. Please dismantle the
shorting busbar before installation, then install the switches to corresponding shorting busbars.
Figure 9.14 I/O sw itch assem b ly
N o. Descriptio n
1 Input switch
2 Bypass switch
3 Output switch
