9.2.15 Top Fan Assembly

As shown in Figure 9.13 below, the top fan kit consists of two fans which are installed on top of the cabinet.

Figure 9.13 T op fan assem bly

N o. Descriptio n

1 Top fan assembly

9 Options

158

Vertiv™ Liebert® APM Plus User Manual
