9.2.19 LBS Adapter
The LBS adapter is designed to extend the LBS function up to 150 m between the two UPS units or systems of a dual bus
system, and it also enables an APM UPS to synchronize with other UPS models.
Appearance
The appearance of the LBS adapter is shown in Figure 9.17 below.
Figure 9.17 A p pearance of LBS Adap ter
N o. Descriptio n
1 Power Port
2 LED1
3 COM1
4 Yellow LED
5 COM2
6 Green LED
7 Switch
For details about how to install and connect cables, see Dual-Bus UPS LBSTM Expander/Adapter Installation Manual.
9 Options
162
Vertiv™ Liebert® APM Plus User Manual
