Vertiv™ NetSure™ 5100 Series -48 VDC Power System Installation Manual
Proprietary and Confidential © 2023 Vertiv Group Corp.
Mounting the Distribution Cabinet with Module Mounting Assembly Using 19” to 23” Wide Relay Rack
Mounting Bracket Kit P/N 553630
The 19” to 23” wide relay rack mounting bracket kit (P/N 553630) allows mounting of a 6RU system consisting of a 19” wide 1-row
distribution cabinet (582137100 List 20) and two (2) 19” wide module mounting assemblies (588705300) in a 23” wide relay rack.
NOTE!
The distribution cabinet is factory connected to the module mounting assembly. The distribution cabinet with
module mounting assembly is mounted as a complete assembly.
Perform the following steps to mount the distribution cabinet with module mounting assembly.
DANGER! If the system is mounted in a relay rack, the relay rack must be securely anchored to the floor before the
distribution cabinet with module mounting assembly is installed.
DANGER! The distribution cabinet with module mounting assembly is heavy. Use a hoist, battery lift, or other appropriate
lifting device to raise and support the assembly during the installation. Take appropriate precautions to avoid injury.
Procedure
NOTE!
In the next step, install (orient) the kit supplied ground washers so the teeth dig into the mounting brackets for a
secure ground connection.
1. Remove the distribution cabinet with module mounting assembly from its shipping rails or box. Attach the kit supplied
mounting brackets to the 6RU power system using hardware as shown in Figure 3.7. Refer to Figure 3.7 for recommended
torque.
NOTE!
In the next step, install (orient) the kit supplied ground washers so the teeth dig into the mounting brackets for a
secure ground connection.
2. Mount the 6RU power system with the mounting bracket kit installed to the 23” relay rack using hardware as shown in
Figure 3.7. Refer to Figure 3.7 for recommended torque.
