VIDEOJET DataFlex 6530 - 4.8 Working with the Configurable Inputs and Outputs

Videojet DataFlex 6530 Operator Manual - Rev AA 5-13
CLARiTY Operating System
Cassette Open The status of the cassette. The
cassette home sensor detects whether
the cassette is open or closed.
Printhead to Platten Distance The distance between the printhead
and platten.
Printhead Position Sensor The position of the printhead position
sensor.
Ribbon Waste Position Sensor The position of the ribbon waste
position sensor.
Optical Calibration Sensor The optical calibration sensor value.
iAssure Sensor The iAssure sensor value.
Motor Volts The voltage supply to the
stepper motors.
24 Volts Supply The health status of the voltage supply
for the printers I/O.
Printhead Volts The drive voltage of the
printhead. This varies, depending on
the printhead resistance but should be
in the range of 23V.
Printhead Temperature The real-time reading of the thermistor
on the thermal printhead.
Controller PCB Temperature The real-time reading of the thermistor
on the CLARiTY Controller PCB.
Option Description
Table 5-9: Inputs Screen Description (continued)
