5-22 Videojet DataFlex 6530 Operator Manual - Rev AA
CLARiTY Operating System
Profile Type The following profile types are
available:
• Standard
• Printer Performance
• Inputs and Outputs
Each profile type presents the
information in slightly different
graphical forms. Select the one which
best suits the requirement.
Profile X Axis Set the X axis of the chart to be either
time or distance.
Option Description
Table 5-16: Encoder Profile Screen Description (continued)
