Chapter 4 Deployment of the CPU 21x-2BT10 with TCP/IP Manual VIPA CPU 21x
4-36 HB103E - Rev. 05/45
... continue DONE, ERROR, STATUS
DONE
(SEND)
NDR
(RECV)
ERROR STATUS Description
0 - 1 8F42h Acknowledgement delay at reading a parameter from
peripheral area.
- 0 1 8F43h Acknowledgement delay at writing a parameter from
peripheral area.
0 - 1 8F44h Address of the parameter to read locked in access
track
- 0 1 8F45h Address of the parameter to write locked in access
track
0 0 1 8F7Fh Internal error e.g. invalid ANY reference e.g. parameter
LEN = 0 .
0 0 1 8090h Module with this module start address not present or
CPU in STOP.
0 0 1 8091h Module start address not within double word grid.
0 0 1 8092h ANY reference contains type setting unequal BYTE.
- 0 1 80A0h Negative acknowledgement at reading the module
0 0 1 80A4h reserved
0 0 1 80B0h Module doesn’t recognize record set.
0 0 1 80B1h The length setting (in parameter LEN) is invalid.
0 0 1 80B2h reserved
0 0 1 80C0h Record set not readable.
0 0 1 80C1h The set record set is still in process.
0 0 1 80C2h Order accumulation.
0 0 1 80C3h The operating sources (memory) of the CPU are
temporarily occupied.
0 0 1 80C4h Communication error (occurs temporarily; a repetition in
the user application is reasonable.)
0 0 1 80D2h Module start address is wrong.
At a reboot of the CP, the output parameter are set back as follows:
• DONE = 0
• NDR = 0
• ERROR = 8180h (at AG_RECV)
ERROR = 8181h (at AG_SEND)
Status parameter at
reboot
