Manual VIPA CPU 21x Chapter 4 Deployment of the CPU 21x-2BT10 with TCP/IP
HB103E - Rev. 05/45 4-35
The following table shows all messages that can be returned by the CP
after a SEND res. RECV command.
A "-" means that this message is not available for the concerning SEND
res. RECV command.
DONE
(SEND)
NDR
(RECV)
ERROR STATUS Description
1 - 0 0000h Order ready without error
- 1 0 0000h New data received without error
0 - 0 0000h No order present
- 0 0 8180h No data available yet
0 0 0 8181h Order running
0 0 1 8183h No CP project engineering for this order
0 - 1 8184h System error
- 0 1 8184h System error (destination data area failure)
0 - 1 8185h Parameter LEN exceeds source area SEND
0 1 8185h Destination buffer (RECV) too small
0 0 1 8186h Parameter ID invalid (not within 1 ...16)
0 - 1 8302h No receive resources at destination station, receive
station is not able to process received data fast enough
res. has no receive resources reserved.
0 - 1 8304h The connection is not established.
The send command shouldn’t be send again before a
delay time of >100 ms.
- 0 1 8304h The connection is not established.
The receive command shouldn’t be send again after a
delay time of >100 ms.
0 - 1 8311h Destination station not available with the defined
Ethernet address.
0 - 1 8312h Ethernet error in the CP
0 1 8F22h Source area invalid, e.g. when area in DB not present
Parameter LEN < 0
- 0 1 8F23h Source area invalid, e.g. when area in DB not present
Parameter LEN < 0
0 - 1 8F24h Range error at reading a parameter.
- 0 1 8F25h Range error at writing a parameter.
0 - 1 8F28h Orientation error at reading a parameter.
- 0 1 8F29h Orientation error at writing a parameter.
- 0 1 8F30h Parameter is within write protected 1
st
recent data block
- 0 1 8F31h Parameter is within write protected 2
nd
recent data
block
0 0 1 8F32h Parameter contains oversized DB number.
0 0 1 8F33h DB number error
0 0 1 8F3Ah Area not loaded (DB)
continued...
DONE, ERROR,
STATUS
