Chapter 8 Deployment CPU 21xCAN Manual VIPA CPU 21x
8-34 HB103E - Rev. 05/45
Index Sub-
index
Name Type Attr. Map. Default value Meaning
0xA400 0x00 8bit digital
output block
Unsigned8 ro N 0x01 Number of available digital
8-bit output blocks
0x01 1
st
output
block
Unsigned8 rw Y 1st digital output block
... ... ... ... ... ... ...
0x140 320
th
output
block
Unsigned8 rw Y 320 nd digital output block
Index Sub-
index
Name Type Attr. Map. Default value Meaning
0xA580 0x00 16bit digital
input block
Unsigned8 ro N Depending on
the compo-
nents fitted
Number of available digital
16-bit output blocks
0x01 1
st
output
block
Unsigned16 rw N 1st digital output block
... ... ... ... ... ... ...
0xA0 160
th
output
block
Unsigned16 rw N 160 th digital output block
Index Sub-
index
Name Type Attr. Map. Default value Meaning
0xA680 0x00 32bit digital
input block
Unsigned8 ro N Depending on
the compo-
nents fitted
Number of available digital
32-bit output blocks
0x01 1
st
output
block
Unsigned32 rw N 1st digital output block
... ... ... ... ... ... ...
0x50 80
th
output
block
Unsigned32 rw N 80 digital output block
Index Sub-
index
Name Type Attr. Map. Default value Meaning
0xA8C0 0x00 64bit digital
input block
Unsigned8 ro N Depending on
the compo-
nents fitted
Number of available digital
64-bit output blocks
0x01 1
st
output
block
Unsigned32 rw N 1st digital output block
... ... ... ... ... ... ...
0x50 40
th
output
block
Unsigned32 rw N 40 digital output block
8bit Network output variables
16bit Network output variables
32bit Network output variables
64bit Network output variables
