Manual VIPA CPU 21x Chapter 10 Deployment CPU 21xSER-2
HB103E - Rev. 05/45 10-13
for PROTOCOL_3964(R):
Data byte Type Designator Values Default
Transmit-/ receive
channel
8, 9 WORD BufAnz 1..n 1
10, 11 WORD BufSize 16..1024 128
12, 13 WORD ZNA, time delay after job 0..n 0
14, 15 WORD ZVZ char. overdue time 1..n 200
16, 17 WORD QVZ ack. overdue time 1..n 500
18, 19 WORD BWZ block delay time ( 1..n 10000
20, 21 WORD STX number of retries
connection set-up
1..n 3
22, 23 WORD DBL number of retries
data blocks
1..n 6
24, 25 WORD Priority 0==Low, >0==High 0, 1 1
wenn PROTOCOL_3964(R)_RK512:
Data byte Type Designator Values Default
Transmit-/ receive
channel
8, 9 WORD BufAnz 1..n 1
10, 11 WORD BufSize 16..1024 128
12, 13 WORD ZNA, time delay after job 0..n 0
14, 15 WORD ZVZ char. overdue time 1..n 200
16, 17 WORD QVZ ack. overdue time 1..n 500
18, 19 WORD BWZ block delay time 1..n 10000
20, 21 WORD STX number of retries
connection set-up
1..n 3
22, 23 WORD DBL number of retries
data blocks
1..n 6
24, 25 WORD Priority 0==Low, >0==High 0, 1 1
26, 27 WORD QVZ for user acknowledgement 1..n 5000
The following parameters are constants and can not be changed
Parameter Setting
Page frame base address 0
No. of page frames 1
Job-no. 1: COM 1 SEND
2: COM 1 RECEIVE
3: COM 2 SEND
4: COM 2 RECEIVE
201: for SEND for parameterization
Job priority 2
Constant
parameters
