Chapter 11 Integrated OBs SFBs SFCs Manual VIPA CPU 21x
11-30 HB103E - Rev. 05/45
Interface number
Number of the logical interface (page frame address) to which the
according order refers to.
Parameter type : Integer
Convenient range : 0 ... 255
Job number
The called job number for the logical interface.
Parameter type : Integer
Convenient range : 1 ... 223
Indicator word (double word)
Address of the indicator double word in the user memory where the
processing of the order specified under ANR is shown.
Parameter type : Double word
Convenient range : DW or MW; use either DW and DW+1
or MW and MW+2
The value DW refers to the data block opened before the incoming
call or to the directly specified DB.
Kind of parameterization (direct, indirect)
This parameter defines the kind of data on which the pointer
QUANF points.
0: QANF points directly to the initial data of the source res.
destination data.
1: the pointer QANF/ZANF points to a memory cell, from where on
the source res. destination data are defined (indirect).
2: the pointer QANF/ZANF points to a memory area where the
source res. destination information lies (indirect).
5: the pointer QANF/ZANF points to a memory cell, from where on
the source res. destination data and parameters of the indicator
word are defined (indirect).
6: the pointer QANF/ZANF points to a memory area where the
source res. destination data and parameters of the indicator word
are laying (indirect).
Parameter type : Integer
Convenient entries : 0, 1, 2, 5, 6
Note!
Please regard, that at IND=5 res. IND=6, the parameter ANZW is ignored!
SSNR
ANR
ANZW
IND
