VIPA CPU 21 Series User Manual

Chapter 12 Instruction list Manual VIPA CPU 21x
Command
Operand Parameter Status word Function
Length
in
BR CC1 CC0 OV OS OR STA RLO /FC
words
: Instruction depends on
: Instruction influences
12-28 HB103E - Rev. 05/45
ON
BR CC1 CC0 OV OS OR STA RLO /FC
OR operation at signal state "0"
I/Q a.b
0.0 ... 127.7
- - - - - - - Y Y Input/output 1/2
M a.b
0.0 ... 1023.7
- - - - - 0 Y Y 1 Bit memory 1/2
L a.b
0.0 ... 1043.7
Local data bit 2
DBX a.b
0.0 ... 8191.7
Data bit 2
DIX a.b
0.0 ... 8191.7
Instance data bit 2
c [AR1,m] register-indirect, area-internal (AR1) 2
c [AR2,m] register-indirect, area-internal (AR2) 2
[AR1,m] area-crossing (AR1) 2
[AR2,m] area-crossing (AR2) 2
Parameter via parameters 2
X
BR CC1 CC0 OV OS OR STA RLO /FC
EXCLUSIVE-OR operation at signal state "1"
I/Q a.b
0.0 ... 127.7
- - - - - - - Y Y Input/output 2
M a.b
0.0 ... 1023.7
- - - - - 0 Y Y 1 Bit memory 2
L a.b
0.0 ... 1043.7
Local data bit 2
DBX a.b
0.0 ... 8191.7
data bit 2
DIX a.b
0.0 ... 8191.7
Instance data bit 2
c [AR1,m] register-indirect, area-internal (AR1) 2
c [AR2,m] register-indirect, area-internal (AR2) 2
[AR1,m] area-crossing (AR1) 2
[AR2,m] area-crossing (AR2) 2
Parameter via parameters 2
XN
BR CC1 CC0 OV OS OR STA RLO /FC
EXCLUSIVE-OR operation at signal state "0"
I/Q a.b
0.0 ... 127.7
- - - - - - - Y Y Input/output 2
M a.b
0.0 ... 1023.7
- - - - - 0 Y Y 1 Bit memory 2
L a.b
0.0 ... 1043.7
Local data bit 2
DBX a.b
0.0 ... 8191.7
Data bit 2
DIX a.b
0.0 ... 8191.7
Instance data bit 2
c [AR1,m] register-indirect, area-internal (AR1) 2
c [AR2,m] register-indirect, area-internal (AR2) 2
[AR1,m] area-crossing (AR1) 2
[AR2,m] area-crossing (AR2) 2
Parameter via parameters 2
