Manual VIPA CPU 21x Chapter 2 Hardware description
HB103E - Rev. 05/45 2-27
Module specific VIPA 214-2BS12...216-2BS12 VIPA 214-2BS32...216-2BS32
Power supply DC 24V (20.4 ... 28.8)
Current consumption max. 1.5A
Dissipation power max. 5W
Potential separation
≥ 500V AC to serial interface
Status indicator (LEDs) like CPU 21x
RS232C interface integrated yes -
RS485 interface integrated - yes
Dimensions and weight
Dimensions (WxHxD) in mm 50.8x76x80
Weight 150g
Electrical data VIPA 214-2BS02 ... VIPA 216-2BS02
Power supply DC 24V (20.4 ... 28.8V)
Current consumption max. 1.5A
Dissipation power max. 5W
Potential separation -
Status indicator (LEDs) like CPU 21x additionally with LEDs for serial communication
Adapters/interfaces like CPU 21x additionally with
2x 9pin D-type jack (serial communication)
Interfaces
COM 1, COM 2 2 integrated RS232C interfaces
Dimensions and weight
Dimensions (WxHxD) in mm 50.8x76x80
Weight 150g
CPU 21xSER-1
CPU 21xSER-2
