Chapter 3 Deployment CPU 21x Manual VIPA CPU 21x
3-18 HB103E - Rev. 05/45
By means of reserved file names in the CPU 21x you may transfer the
firmware updates per MMC for the following components:
Component Possible with
CPU version
File name at ftp server New file name
at MMC
CPU V. 3.3.3
order no._release.version
firmware.bin
Profibus master V. 3.0.5 Bb000089.version dpm00.bin
*)
CANopen master V. 3.4.8 and
CAN master V. 1.0.7
VIPA_order no._version.bin
can00.bin
CP (21x-2BT10) V. 3.6.7
px000018_version.zip
px000018.pkg
*)
When deploying the CPU firmware version V 3.3.3, the file name of the firmware update has to be dpm.bin!
• Go to ftp.vipa.de/support/firmware
• Navigate to System 200V. Here the components corresponding
firmware can be found.
• Download the corresponding file. The table above can be used for a
check of the file name structure.
• Copy the file to your MMC. Rename the file to the corresponding
reserved file name of the table.
• Get the RUN-STOP lever of your CPU in position STOP.
• Turn off the power supply.
• Plug the MMC with the firmware into the CPU. Please take care of the
correct plug-in direction of the MMC.
• Turn on the power supply.
• After a short boot-up time, the alternate blinking of the LEDs SF and FC
shows that the firmware file has been found on the MMC.
• You start the transfer of the firmware as soon as you tip the RUN/STOP
lever downwards to MRES within 10s. The CPU shows the transfer via a
LED blink line.
• During the update process, the LEDs SF, FC and MC are alternately
blinking. This may last several minutes.
• The update is successful finished when all CPU-LEDs are on. If they are
blinking fast, an error occurred.
Note!
Starting with the WinNCS version 3.1.1 you may update the firmware of the
CP online via the parameterization window. The CP portion supports this
function from CP firmware version 2.1.2 on.
MMC update using
reserved file names
Load firmware and
transfer it to MMC
with reserved file
name
Transfer firmware
from MMC into
CPU
