Vivotek SC8131 - File Name Prefix; Maximum Duration; Maximum File Size; Media Type - System Log

VIVOTEK
110 - User's Manual
■ Maximum duration
Specify the maximum recording duration in seconds. Up to 20 seconds can be set.
For example, if pre-event recording is set to 5 seconds and the maximum duration is set to
10 seconds, the Network Camera continues to record for another 4 seconds after a trigger is
activated.
■ Maximum le size
Specify the maximum le size allowed.
■ File name prex
Enter the text that will be appended to the front of the le name.
For example:
Click
Save media
to enable the settings, then click
Close
to exit the Add media page.
Media type - System log
Select to send a system log when a trigger is activated.
Click
Save media
to enable the settings, then click
Close
to exit the Add media page.
1 sec. 2 sec. 3 sec. 4 sec. 5 sec. 6 sec. 7 sec. 8 sec. 9 sec. 10 sec.
Trigger Activation
Video_20110320_100341
Date and time suffix
The format is: YYYYMMDD_HHMMSS
File name prefix
