Vivotek SC8131 - Installation Option A: Using the Mounting Plate

VIVOTEK
User's Manual - 33
Installation Option A: Using the Mounting Plate
A1
Ø15mm
LED
RJ45
Ø15
A1. Attach the alignment sticker to a preferred position. If preferred, drill a cabling
hole. See below for the diameters of it.
LED
RJ45
Ø15
A2
A2. Route an Ethernet cable through the cabling hole.
