VIVOTEK
34 - User's Manual
LED
RJ45
Ø15
1
2
A3
A3. Drill mounting holes and hammer the included anchors into the mounting holes.
LED
RJ45
Ø15
A4
A4. Secure the mounting plate to ceiling using the included screws.
