VIVOTEK
User's Manual - 35
RJ45
LED
RJ45
Ø15
A5
A5. Connect the Ethernet cable to the camera.
LED
RJ45
Ø15
1
2
A6
A6. Align the camera with the bracket, and slide the camera to the right. The camera
will then be securely mounted to the bracket. Note that the side with two LEDs is
the top side, and should be aligned with the arrow mark on the mounting plate.
