Vivotek SC8131 User Manual

VIVOTEK
10 - User's Manual
SC8131-F2
* Unit in centimeter.
** The number in front of HFOV (Horizontal FOV) stands for zoom ratio, if applied.
Zoom ratio 1.0 1.1 1.2 1.3 1.4 1.5 1.6 1.7 1.8
FOV (Horizontal) HFOV HFOV HFOV HFOV HFOV HFOV HFOV HFOV HFOV
Distance with next camera
(H)*
Height
140.1 240 254.8 242.1 229.4 216.6 203.9 191.1 178.4 165.6 152.9
191.1 260 305.8 290.5 275.2 259.9 244.6 229.4 214.1 198.8 183.5
242.0 280 356.8 338.9 321.1 303.3 285.4 267.6 249.7 231.9 214.1
293.0 300 407.7 387.4 367.0 346.6 326.2 305.8 285.4 265.0 244.6
344.0 320 458.7 435.8 412.8 389.9 367.0 344.0 321.1 298.2 275.2
395.0 340 509.7 484.2 458.7 433.2 407.7 382.3 356.8 331.3 305.8
445.9 360 560.6 532.6 504.6 476.6 448.5 420.5 392.5 364.4 336.4
380 581.0 550.5 519.9 489.3 458.7 428.1 397.6 367.0
400 563.2 530.1 496.9 463.8 430.7 397.6
420 570.8 535.2 499.5 463.8 428.1
440 573.4 535.2 496.9 458.7
460 570.8 530.1 489.3
480 563.2 519.9
500 550.5
* Distance between cameras when congured in a stitching conguration.
SC8131(F2): 240~500 cm (7.9~16.4')
SC8131(F4): 500~800 cm (16.4~26.2')
SC8131(F6): 800~1000 cm (26.2~32.8')
Installation Heights

Vivotek SC8131 Specifications

General

Built-in HDD	No
Flash memory	256 MB
Card reader integrated	Yes
Compatible memory cards	MicroSD (TransFlash), MicroSDHC, MicroSDXC
Sensor type	CMOS
Optical sensor size	1/3 \
Maximum resolution	2560 x 960 pixels
Video formats supported	H.264, M-JPEG
Power consumption	300 mA
Power source type	PoE
Power consumption (Power over Ethernet (PoE))	12.95 W
Type	IP security camera
Certification	CE, LVD, FCC B, VCCI, C-Tick, UL
Placement supported	Indoor
Connectivity technology	Wired
Interface	RJ-45
Form factor	-
Mounting type	Ceiling
Product color	White
LED indicators	Power, Status
Networking standards	IEEE 802.3af
Number of cameras	1
Operating temperature (T-T)	-10 - 40 °C
Windows operating systems supported	Windows 2000, Windows 7, Windows 8, Windows Vista, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Intelligent Video Surveillance (IVS) system features	People counting
Minimum illumination	- lx

Weight and Dimensions

Depth	160 mm
Width	70 mm
Height	38 mm
Weight	396 g
