Requirements for Running Stereo Tracking Video Analysis:
1.
The recommended installation height ranges from
2.4
to
3.6
meters. If the camera is
unavoidably installed in a position higher than
3.6m
, you can use the zoom-in mode
operation. Different lens provide different FOVs. See the FOV tables at page 9 for
details.
2.
The embedded video tracking and counting analysis requires a monitoring session on
Microsoft IE 10 or IE 11 browser.
3.
Lens cleanliness is also required because dust spots or smears on dirty lens can
produce miscalculation of pixels, correlation, and movements.
4.
Avoid impacts to the lens modules. The relative positions of the lens have been carefully
calibrated in factory. Even if the lens positions have slightly changed, optical parameters
and stereo correlation will be affected, and then you should return the camera for a
repair.
5.
For other installation concerns, please refer to page 13, Considerations.
6
. Avoid glass and reective materials, such as aluminum foils, in the eld of view. If
unavoidable, you can use the Exclusive area settings to get rid of the side effects.
7.
Make sure the camera is installed appropriately above the area of your interest, e.g.,
an entrance to building. Also use a leveling tool to make sure the camera is mounted
horizontally level.
8
. Due to the system load, do not open two conguration web consoles at the same time.
IMPORTANT:
Refer to page 51 for the conguration details about the embedded
Stereo Tracking
and
Counting
functionality.
NOTE:
•
This camera is powered by a PoE switch or PoE injector. This equipment is to be
connected only to PoE networks without routing the the outside plant.
Symbols and Statements in this Document
i
INFORMATION:
provides important messages or advices that might help prevent
inconvenient or problem situations.
NOTE
: Notices provide guidance or advices that are related to the functional integrity of
the machine.
Tips
: Tips are useful information that helps enhance or facilitate an installation, function,
or process.
WARNING: or IMPORTANT:
: These statements indicate situations that can be
dangerous or hazardous to the machine or you.
Electrical Hazard
: This statement appears when high voltage electrical hazards might
occur to an operator.

Vivotek SC8131 Specifications

General

Built-in HDD	No
Flash memory	256 MB
Card reader integrated	Yes
Compatible memory cards	MicroSD (TransFlash), MicroSDHC, MicroSDXC
Sensor type	CMOS
Optical sensor size	1/3 \
Maximum resolution	2560 x 960 pixels
Video formats supported	H.264, M-JPEG
Power consumption	300 mA
Power source type	PoE
Power consumption (Power over Ethernet (PoE))	12.95 W
Type	IP security camera
Certification	CE, LVD, FCC B, VCCI, C-Tick, UL
Placement supported	Indoor
Connectivity technology	Wired
Interface	RJ-45
Form factor	-
Mounting type	Ceiling
Product color	White
LED indicators	Power, Status
Networking standards	IEEE 802.3af
Number of cameras	1
Operating temperature (T-T)	-10 - 40 °C
Windows operating systems supported	Windows 2000, Windows 7, Windows 8, Windows Vista, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Intelligent Video Surveillance (IVS) system features	People counting
Minimum illumination	- lx

Weight and Dimensions

Depth	160 mm
Width	70 mm
Height	38 mm
Weight	396 g
