Vivotek SC8131 User Manual

VIVOTEK
User's Manual - 11
SC8131-F4
Zoom ratio 1.0 1.1 1.2 1.3 1.4
FOV (Horizontal / Vertical) HFOV VFOV HFOV VFOV HFOV VFOV HFOV VFOV HFOV VFOV
Distance with next camera
(H)*
Height
225.0 360 274.9 177.8 261.2 168.9 247.4 160.0 233.7 151.1 220.0 142.2
249.9 380 299.9 193.9 284.9 184.2 269.9 174.5 254.9 164.8 239.9 155.1
274.9 400 324.9 210.1 308.7 199.6 292.4 189.1 276.2 178.6 259.9 168.1
299.9 420 349.9 226.3 332.4 214.9 314.9 203.6 297.4 192.3 279.9 181.0
324.9 440 374.9 242.4 356.2 230.3 337.4 218.2 318.7 206.1 299.9 193.9
349.9 460 399.9 258.6 379.9 245.6 359.9 232.7 339.9 219.8 319.9 206.9
374.9 480 424.9 274.7 403.7 261.0 382.4 247.3 361.2 233.5 339.9 219.8
399.9 500 449.9 290.9 427.4 276.4 404.9 261.8 382.4 247.3 359.9 232.7
424.9 520 474.9 307.1 451.2 291.7 427.4 276.4 403.7 261.0 379.9 245.6
449.9 540 499.9 323.2 474.9 307.1 449.9 290.9 424.9 274.7 399.9 258.6
474.9 560 524.9 339.4 498.6 322.4 472.4 305.4 446.2 288.5 419.9 271.5
499.9 580 549.9 355.5 522.4 337.8 494.9 320.0 467.4 302.2 439.9 284.4
600 546.1 353.1 517.4 334.5 488.6 315.9 459.9 297.4
620 539.9 349.1 509.9 329.7 479.9 310.3
640 531.1 343.4 499.9 323.2
680 539.9 349.1
700 559.9 362.0
720
740
760
780
800
820
840
860
880
* Distance between cameras when congured in a stitching conguration.
1.5 1.6 1.7 1.8
HFOV VFOV HFOV VFOV HFOV VFOV HFOV VFOV
360 206.2 133.3 192.5 124.4 178.7 115.6 165.0 106.7
380 225.0 145.4 210.0 135.8 195.0 126.1 180.0 116.4
400 243.7 157.6 227.5 147.1 211.2 136.6 195.0 126.1
420 262.4 169.7 244.9 158.4 227.5 147.1 210.0 135.8
440 281.2 181.8 262.4 169.7 243.7 157.6 225.0 145.4
460 299.9 193.9 279.9 181.0 259.9 168.1 239.9 155.1
480 318.7 206.1 297.4 192.3 276.2 178.6 254.9 164.8
500 337.4 218.2 314.9 203.6 292.4 189.1 269.9 174.5
520 356.2 230.3 332.4 214.9 308.7 199.6 284.9 184.2
540 374.9 242.4 349.9 226.3 324.9 210.1 299.9 193.9
560 393.7 254.5 367.4 237.6 341.2 220.6 314.9 203.6
580 412.4 266.7 384.9 248.9 357.4 231.1 329.9 213.3
600 431.2 278.8 402.4 260.2 373.7 241.6 344.9 223.0
620 449.9 290.9 419.9 271.5 389.9 252.1 359.9 232.7
640 468.7 303.0 437.4 282.8 406.2 262.6 374.9 242.4
680 506.1 327.3 472.4 305.4 438.7 283.6 404.9 261.8
700 524.9 339.4 489.9 316.8 454.9 294.1 419.9 271.5
720 543.6 351.5 507.4 328.1 471.2 304.6 434.9 281.2
740 524.9 339.4 487.4 315.1 449.9 290.9
760 542.4 350.7 503.6 325.6 464.9 300.6
780 519.9 336.1 479.9 310.3
800 536.1 346.7 494.9 320.0
820 552.4 357.2 509.9 329.7
840 524.9 339.4
860 539.9 349.1
880 554.9 358.8

Vivotek SC8131 Specifications

General

Built-in HDD	No
Flash memory	256 MB
Card reader integrated	Yes
Compatible memory cards	MicroSD (TransFlash), MicroSDHC, MicroSDXC
Sensor type	CMOS
Optical sensor size	1/3 \
Maximum resolution	2560 x 960 pixels
Video formats supported	H.264, M-JPEG
Power consumption	300 mA
Power source type	PoE
Power consumption (Power over Ethernet (PoE))	12.95 W
Type	IP security camera
Certification	CE, LVD, FCC B, VCCI, C-Tick, UL
Placement supported	Indoor
Connectivity technology	Wired
Interface	RJ-45
Form factor	-
Mounting type	Ceiling
Product color	White
LED indicators	Power, Status
Networking standards	IEEE 802.3af
Number of cameras	1
Operating temperature (T-T)	-10 - 40 °C
Windows operating systems supported	Windows 2000, Windows 7, Windows 8, Windows Vista, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Intelligent Video Surveillance (IVS) system features	People counting
Minimum illumination	- lx

Weight and Dimensions

Depth	160 mm
Width	70 mm
Height	38 mm
Weight	396 g
