Vivotek SC8131 User Manual

VIVOTEK
12 - User's Manual
SC8131-F6
Zoom ratio 1.0 1.1 1.2 1.3 1.4
FOV (Horizontal / Vertical) HFOV VFOV HFOV VFOV HFOV VFOV HFOV VFOV HFOV VFOV
Distance with next camera
(H)*
Height
147.6 500 295.3 209.9 280.5 199.4 265.8 188.9 251.0 178.4 236.2 167.9
164.1 520 311.7 221.5 296.1 210.4 280.5 199.4 264.9 188.3 249.4 177.2
180.5 540 328.1 233.2 311.7 221.5 295.3 209.9 278.9 198.2 262.5 186.5
196.9 560 344.5 244.8 327.3 232.6 310.1 220.4 292.8 208.1 275.6 195.9
213.3 580 360.9 256.5 342.9 243.7 324.8 230.8 306.8 218.0 288.7 205.2
229.7 600 377.3 268.2 358.5 254.7 339.6 241.3 320.7 227.9 301.9 214.5
246.1 620 393.7 279.8 374.0 265.8 354.4 251.8 334.7 237.8 315.0 223.9
262.5 640 410.1 291.5 389.6 276.9 369.1 262.3 348.6 247.8 328.1 233.2
278.9 680 442.9 314.8 420.8 299.1 398.6 283.3 376.5 267.6 354.4 251.8
295.3 700 459.3 326.5 436.4 310.1 413.4 293.8 390.4 277.5 367.5 261.2
311.7 720 475.8 338.1 452.0 321.2 428.2 304.3 404.4 287.4 380.6 270.5
328.1 740 492.2 349.8 467.5 332.3 442.9 314.8 418.3 297.3 393.7 279.8
344.5 760 508.6 361.4 483.1 343.4 457.7 325.3 432.3 307.2 406.8 289.1
360.9 780 525.0 373.1 498.7 354.4 472.5 335.8 446.2 317.1 420.0 298.5
377.3 800 541.4 384.7 514.3 365.5 487.2 346.3 460.2 327.0 433.1 307.8
410.1 820 557.8 396.4 529.9 376.6 502.0 356.8 474.1 336.9 446.2 317.1
840 545.5 387.7 516.8 367.3 488.1 346.9 459.3 326.5
860 561.1 398.7 531.5 377.7 502.0 356.8 472.5 335.8
880 546.3 388.2 515.9 366.7 485.6 345.1
900 561.1 398.7 529.9 376.6 498.7 354.4
920 543.8 386.5 511.8 363.8
940 557.8 396.4 525.0 373.1
960 538.1 382.4
980 551.2 391.7
1000
* Distance between cameras when congured in a stitching conguration.
1.5 1.6 1.7 1.8
HFOV VFOV HFOV VFOV HFOV VFOV HFOV VFOV
500 221.5 157.4 206.7 146.9 191.9 136.4 177.2 125.9
520 233.8 166.1 218.2 155.1 202.6 144.0 187.0 132.9
540 246.1 174.9 229.7 163.2 213.3 151.6 196.9 139.9
560 258.4 183.6 241.2 171.4 223.9 159.1 206.7 146.9
580 270.7 192.4 252.6 179.5 234.6 166.7 216.5 153.9
600 283.0 201.1 264.1 187.7 245.3 174.3 226.4 160.9
620 295.3 209.9 275.6 195.9 255.9 181.9 236.2 167.9
640 307.6 218.6 287.1 204.0 266.6 189.5 246.1 174.9
680 332.2 236.1 310.1 220.4 287.9 204.6 265.8 188.9
700 344.5 244.8 321.5 228.5 298.6 212.2 275.6 195.9
720 356.8 253.6 333.0 236.7 309.2 219.8 285.5 202.9
740 369.1 262.3 344.5 244.8 319.9 227.3 295.3 209.9
760 381.4 271.1 356.0 253.0 330.6 234.9 305.1 216.9
780 393.7 279.8 367.5 261.2 341.2 242.5 315.0 223.9
800 406.0 288.6 379.0 269.3 351.9 250.1 324.8 230.8
820 418.3 297.3 390.4 277.5 362.6 257.7 334.7 237.8
840 430.6 306.0 401.9 285.6 373.2 265.2 344.5 244.8
860 442.9 314.8 413.4 293.8 383.9 272.8 354.4 251.8
880 455.2 323.5 424.9 302.0 394.5 280.4 364.2 258.8
900 467.5 332.3 436.4 310.1 405.2 288.0 374.0 265.8
920 479.9 341.0 447.9 318.3 415.9 295.6 383.9 272.8
940 492.2 349.8 459.3 326.5 426.5 303.1 393.7 279.8
960 504.5 358.5 470.8 334.6 437.2 310.7 403.6 286.8
980 516.8 367.3 482.3 342.8 447.9 318.3 413.4 293.8
1000 529.1 376.0 493.8 350.9 458.5 325.9 423.3 300.8

Vivotek SC8131 Specifications

General

Built-in HDD	No
Flash memory	256 MB
Card reader integrated	Yes
Compatible memory cards	MicroSD (TransFlash), MicroSDHC, MicroSDXC
Sensor type	CMOS
Optical sensor size	1/3 \
Maximum resolution	2560 x 960 pixels
Video formats supported	H.264, M-JPEG
Power consumption	300 mA
Power source type	PoE
Power consumption (Power over Ethernet (PoE))	12.95 W
Type	IP security camera
Certification	CE, LVD, FCC B, VCCI, C-Tick, UL
Placement supported	Indoor
Connectivity technology	Wired
Interface	RJ-45
Form factor	-
Mounting type	Ceiling
Product color	White
LED indicators	Power, Status
Networking standards	IEEE 802.3af
Number of cameras	1
Operating temperature (T-T)	-10 - 40 °C
Windows operating systems supported	Windows 2000, Windows 7, Windows 8, Windows Vista, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Intelligent Video Surveillance (IVS) system features	People counting
Minimum illumination	- lx

Weight and Dimensions

Depth	160 mm
Width	70 mm
Height	38 mm
Weight	396 g
