2-90 CO Line - Loop Supervision
Features and Operation
STARPLUS STSe - Programming & Operations Manual August 2005
2. Enter the range of fixed station numbers (100-149) to be programmed. If only one station
is being programmed, enter that number twice, e.g., [100 100].
-or-
Enter a valid flexible number (100-8999) to be programmed.
3. Press HOLD to save the entry. A confirmation tone sounds and the display updates.
Flexible button #19 is lit. The display updates to reflect current programming for Page A:
4. Press button #21. The display updates to reflect current programming for Page C.
5. Press the SLT SUPERVISION button (Button #7). The following message displays:
6. Dial a valid number [0] to disable or [1] to enable SLT Loop Supervision.
7. Press HOLD to save the entry.
DEFAULT … The SLT Loop Supervision setting is [1] (enabled).
Conditions
» Only one station at a time can be programmed when using a flexible station number.
» When in Flash 51 programming, if you press HOLD without specifying a flexible number
to be programmed, you will get the station that is in port/station 100.
If HOLD is pressed without entering a station range, all stations are selected.
Flash 50 - Fixed Numbers Flash 51 - Flexible Numbers
XXX - XXX PAGE A
ENTER BUTTON NUMBER
SXXX PAGE A
ENTER BUTTON NUMBER
XXX-XXX = fixed station range XXX = 3- or 4-digit flexible number
Flash 50 - Fixed Numbers Flash 51 - Flexible Numbers
XXX - XXX PAGE C
ENTER BUTTON NUMBER
SXXX PAGE C
ENTER BUTTON NUMBER
XXX-XXX = fixed station range XXX = 3- or 4-digit flexible number
SLT SUPERVISION 0-1
ENABLED
