D-4 Programming the Voice Mail System
Hard Drive-Based Voice Mail
STARPLUS STSe - Programming & Operations Manual August 2005
Programming the Voice Mail System
The following STSe system features must be programmed using a touch tone telephone and
a personal computer. This section describe these system programming requirements.
Card Slot Programming
By default, slot 7 of the STSe BKSU is already configured for a Voice Mail Interface Board when
it comes from the factory.
» If this card slot setting has been changed, or you are unsure of its configuration, complete
the steps in the next procedure.
Description
The Card Slot Programming feature provides a means to assign the peripheral cards to
alternative peripheral card slots. The Voice Mail Interface Board can only be installed in slot 7
of the BKSU.
Programming Steps
1. Press FLASH and dial [24]. The following message displays:
2. Press flexible Button #8 to designate slot 7.
3. Enter a valid number to identify the type of card plugged into slot 7:
[17] = VM1B (represents Hard Drive-based VMIB).
4. Press HOLD to save the entry. A confirmation tone sounds and the display updates.
5. Press the reset button on the Main Board Unit (MBU).
Conditions
» After programming the card slot, a system reset must be performed using FLASH 80,
Button 20. For more details, refer to “System Reset” on page 2-298.
» If a caller ID card is used in the system, you must use FLASH 40, Page C, Button #2 to set
the Ring Delay Timer to a setting of 05 (sec). This allows sufficient time for receipt of ICLID
information from the telephone company. Refer to “Ring Delay Timer” on page A-9.
CABINET 0
ENTER BUTTON NUMBER
CAB 0 SLOT XX 00-18
DTIB
