T-1 Tr unking 2-311
Features and Operation
STARPLUS STSe - Programming & Operations Manual August 2005
T-1 Framing Type
Description
The T-1 board will work with D4SF-AMI or ESF-B8ZS framing. The T-1 service should be
ordered from the serving company.
Programming Steps
There are two types of T-1 Framing Types available. To change the framing type:
1. Press the T-1 FRAMING TYPE flexible button (FLASH 41, Button #7) for programming the
type of T-1 Framing desired. The following message is shown on the display phone:
2. Enter a 0 or 1 on the dial pad.
[0] = D4SF-AMI
[1] = ESF-B8ZS
3. Press the HOLD button to save the entry. A confirmation tone sounds and the display
updates.
DEFAULT … T-1 Framing type is set for D4SF-AMI.
T1 FRAMING TYPE 0-1
D4SF-AMI
