T-1 Tr unking 2-309
Features and Operation
STARPLUS STSe - Programming & Operations Manual August 2005
Wink Timer
Description
When Wink signaling is programmed, this timer determines how long the STSe system keeps
the T-1 TIE Line circuit reversed before any DTMF digits are sent from the Central Office. This
option allows the installer a method to adjust the Wink Signal on a per CO Line basis. The
Wink Signal can be used on DID and TIE-type trunks.
Programming Steps
1. Press FLASH and dial [40]. The following message displays:
2. Enter a valid number for the range of lines being programmed. If only one line is being
programmed, enter that number twice (001 001).
3. Press Button #21 to select Page C. The display updates. The following message displays to
indicate current programming of that line or group of lines:
XXX-XXX = CO Line Range
4. Press the WINK TIMER Button (FLASH 40, Page C, Button #3) in the flexible button field.
The following message displays:
5. Enter a valid number which corresponds to 100-290 ms.
6. Press HOLD button to save entry. A confirmation tone sounds and the display updates.
DEFAULT … Wink Timer is set for 140 ms.
CO LINE ATTRIBUTES
SELECT A CO LINE RANGE
If HOLD is pressed without entering a CO line range, all CO lines are selected.
XXX - XXX PAGE C
ENTER BUTTON NUMBER
WINK TIMER 100-290
140
