Slip calibration
Volvo Penta Lowspeed/trolling
D4, D6, D9, D12
WARNING! This procedure requires engine run-
ning at idle speed and with gear engagement.
Moor the boat in a proper and safety way.
WARNING! During the calibration seqence for-
ward gear will automatically be engaged and
disengaged for several times.
1. Enter calibration mode
2. Push and hold MULTIFUNCTION button and
NEUTRAL button for 5 seconds to enter SLIP
CALIBRATION.
Display reads CALIBRATION SLIP 6.1.
3. Start engine and engage gear. Calibration starts
automatically.
Display reads CALIBRATION SLIP 6.2.
WARNING! The slip function will now be calibrat-
ed. During the calibration seqence forward gear
will automatically be engaged and disengaged
for several times.
NOTE! The time the system needs for slip calibration
may vary from 5–20 minutes depending on transmis-
sion type.
4. When calibration is ready display reads CALI-
BRATION SLIP 6.3.
5. Move the control lever to neutral position.
6. Push the NEUTRAL BUTTON.
Stop the engine, system power down.
95
EVC-C Calibration and settings
