E 3000 Maintenance
Continued from the previous page.
7. Open valve #6 (right hose reel supply valve).
8. Move the right pump switch (b) to the ON position and watch the HTF reservoir
sightglass (c), then move the right pump switch to the OFF position when the
level is between the minimum and maximum marks on the sightglass.
NOTICE: Do not overfill the HTF reservoir. Doing so may damage the machine.
9. Move valve #3 to the normal position.
10.Remove the fill hose from the HTF container. Allow any HTF within the hose to
drip back into the container. Cap the hose if a cap is included.
11.Move the fill hose to its storage location under the hose reel.
12.Open valve #2 and close valve #3 simultaneously.
Result
The HTF reservoir has now been filled.
