E 3000 Operation
4.13 Refueling the Machine
Requirements
Machine shut down
Machine level with the ground
Diesel fuel supply
Procedure
Perform the procedure below to refuel the machine.
Note: On models with generators, it is not necessary to fill the generator’s fuel
tank. Both the burner and the generator use the machine’s fuel tank.
1. Lift the lever (a) on the fuel cap.
2. Rotate the lever counterclockwise until it stops.
3. Remove the fuel cap from the tank.
4. Fill the tank with the appropriate grade of fuel for the weather conditions until the
gauge (b) reads full. Leave room within the tank for possible fuel expansion.
5. Reinstall the fuel cap.
Result
The procedure to refuel the machine is now complete.
wc_gr008446
a
wc_gr008447
wc_gr008448 wc_gr008599
b
CAUTION
Fire and health hazard. Fuel expands when heated. Expanding fuel in a overly-full
tank can lead to spills and leaks.
f Do not overfill the fuel tank.
