Accessories E 3000
5.3 Expanded Operation Using One HHS 3002 and One DPP
Requirements
Machine stopped
One HHS 3002 Hose Handling System
One DPP Dual Pump Pack
Procedure
Perform the procedure below to expand the machine with one Hose Handling
System (HHS) and one Dual Pump Pack (DPP).
1. Position the E 3000 near the application area.
2. Position the DPP (a) near the application area.
3. Unwind and position the hose (b) from the left reel of the E 3000 within the
application area.
4. Unwind and position the hose (c) from the right reel of the E 3000 within the
application area.
5. Unwind and position the hose loop 1 (d) from the HHS 3002 (f) within the
application area.
a.Connect the male quick-connect to the return port (g).
b.Connect the female quick-connect to the DPP (a).
6. Unwind and position the hose loop 2 (e) from the HHS 3002 (c) within the
application area. Place the HHS 3002 frame in a safe place.
a.Connect the male quick-connect to the return port (h).
b.Connect the female quick-connect to the DPP (a).
7. Connect the leader hose of the DPP to the accessory supply port (#1).
8. Connect the electric cord of the DPP to the Auxiliary Pump Panel. See topic
Mounting the Auxiliary Pump Panel.
Result
The machine is now ready for expanded operation.
This procedure continues on the next page.
