Accessories E 3000
5.4 Expanded Operation Using Two HHS 3002 and Two DPP
Requirements  Machine stopped
 Two HHS 3002 Hose Handling Systems
 Two DPP Dual Pump Packs
 Two 2-1 adapters
Procedure Perform the procedure below to expand the machine with two Hose Handling
Systems (HHS) and two Dual Pump Packs (DPP).
1. Position the E 3000 near the application area.
2. Position both DPP (a and m) near the application area.
3. Unwind and position the hose (b) from the left reel of the E 3000 within the
application area.
4. Unwind and position the hose (c) from the right reel of the E 3000 within the
application area.
5. Connect one 2-1 adapter (i) to return port (g).
6. Connect the other 2-1 adapter (j) to return port (h).
7. Unwind and position the hose loop 1 (d) from the first HHS 3002 (f) within the
application area.
a.Connect the male quick-connect to the 2-1 adapter (j).
b.Connect the female quick-connect to the DPP (a).
8. Unwind and position the hose loop 2 (e) from the HHS 3002 (f) within the
application area. Place the HHS 3002 frame in a safe place.
a.Connect the male quick-connect to the 2-1 adapter (j).
b.Connect the female quick-connect to the DPP (a).
9. Unwind and position the hose loop 1 (k) from the second HHS 3002 (n) within
the application area.
a.Connect the male quick-connect to the 2-1 adapter (i).
b.Connect the female quick-connect to the DPP (m).
10.Unwind and position the hose loop 2 (l) from the second HHS 3002 (n) within
the application area. Place the HHS 3002 frame in a safe place.
a.Connect the male quick-connect to the 2-1 adapter (i).
b.Connect the female quick-connect to the DPP (m).
11.Connect the leader hose of the DPP (a) to the accessory supply port (#1).
12.Connect the leader hose of the DPP (m) to the accessory supply port (#7).
13.Connect the electric cord of the first DPP to the Auxiliary Pump Panel. See topic
Mounting the Auxiliary Pump Panel.
14.Connect the electric cord of the second DPP to the duplex receptacle of the
E 3000.
Result The machine is now ready for expanded operation.
This procedure continues on the next page.
